Lenovo ThinkStation P7

share to:

Lenovo ThinkStation P7 is Lenovo’s flagship tower workstation for high-end professional fields, equipped with Intel Xeon W9-3475X processor (2.2GHz, 36 core /72 threads), It is equipped with 64GB DDR5 4800MHz memory and 1TB SSD+4TB HDD mixed storage, supporting multi-task parallel processing and mass data storage 1 5. NVIDIA GeForce RTX 4090 (24GB video memory) makes it easy to handle high-load tasks such as complex 3D modeling, ray tracing rendering and scientific simulation, and supports multi-screen output (up to 6 monitors).

Introduction

The flexibility to tackle complexity

Rack-optimized for those that demand flexibility between desktop environments and data centers, the Lenovo ThinkStation P7 workstation breaks new ground by taking on workloads that were traditionally reserved for cloud or server resources. Designed for data scientists, engineers, and senior creatives, it offers end-to-end workflow performance across game development, 3D rendering, computational fluid dynamics, and more.



Inspired by Aston Martin, built to perform

The bold ThinkStation P7 is a force to be reckoned with. It brings together a breakthrough new computer architecture and an optimized thermal design to maximize performance in a versatile, Aston Martin-inspired chassis. Featuring Intel® Xeon® W processors, up to three NVIDIA® RTX™ discrete graphics cards, robust PCIe Gen 5 connectivity, and high-speed DDR5 memory, it delivers staggering performance in a single-socket platform.



Game-changing reliability

At the heart of the ThinkStation P7 is reliability and durability. By meeting Lenovo’s exacting standards, it delivers maximum uptime and is perfect for mission-critical environments. It also comes with an array of independent software vendor (ISV) certifications, so you can be sure that it will zip through massive datasets and compute-intensive, multithreaded tasks in applications such as AVID®,  Bentley®, and PTC®.



Engineered for the real world

The ThinkStation P7 is a breeze to customize and upgrade, thanks to front drive access, hot-swap drives*, and a tool-less chassis. It has a choice of power supply options to fit your most demanding workload requirements. Plus, you can take pride knowing that your workstation is EPEAT Gold registered and was manufactured and packaged responsibly, while never compromising on quality nor performance.



We’ve got your back

The ThinkStation P7 comes with ThinkShield—a suite of essential hardware and software security solutions that work together to safeguard both your device and your data. This includes the Trusted Platform Module (TPM) that encrypts your data, plus various programs to prevent unauthorized access to the BIOS—and even self-heal the BIOS should it become corrupt or is maliciously attacked.

Specifications

Tech Specs
PERFORMANCE
Processor Up to Intel vPro®with Intel®Xeon®W9-3595X (60 cores, 2.0GHz, 112.5MB cache, 385W)
Operating System Windows 11 Pro for Workstations
Ubuntu Linux®*
Red Hat®Enterprise Linux®(certified)
Graphics Optional: Choose up to 3 in total:
NVIDIA® RTX™ 6000 Ada (48GB GDDR6)
NVIDIA® RTX™ 5000 Ada (32GB GDDR6)
NVIDIA® RTX™ 4500 Ada (24GB GDDR6)
NVIDIA® RTX™ 4000 Ada (20GB GDDR6)
NVIDIA® RTX™ 2000 Ada (16GB GDDR6)
NVIDIA® RTX™ A6000 (48GB GDDR6)
NVIDIA® RTX™ A5500 (24GB GDDR6)
NVIDIA® RTX™ A4500 (20GB GDDR6)
NVIDIA® RTX™ A4000 (16GB GDDR6)
NVIDIA® RTX™ A2000 (12GB GDDR6)
NVIDIA® RTX™ A1000 (8GB GDDR6)
NVIDIA® T1000 (8GB GDDR6)
NVIDIA® T400 (4GB GDDR6)
Memory Up to 1TB DDR5 4800MHz*
Storage Up to 7 drives in total:
Supports up to 4 maximum, 4TB M.2 NVMe PCIe SSD
Supports up to 3 maximum, 12TB 3.5″ SATA 7200rpm
Or
Up to 6 drives in total:
Supports up to 5 maximum, 4TB M.2 NVMe PCIe SSD
Supports up to 1 maximum, 12TB 3.5″ SATA 7200rpm
RAID M.2 = 0 / 1 / 10 / 5*
SATA = 0 / 1 / 10 / 5*
Audio Realtek®
CONNECTIVITY
Ports/Slots Front:
Headphone / mic combo

Optional Front:
2 x USB-A (USB 10Gbps, 1 always on)
2 x USB-C® (USB 10Gbps)

Rear:
2 x USB-A (Hi-Speed USB)
3 x USB-A (USB 10Gbps)
USB-C (USB 20Gbps)
2 x Ethernet (RJ45): 1 x 1Gbps, 1 x 10Gbps
Line in
Line out

Optional Rear:
Serial

Network Onboard Ethernet
Intel®Ethernet I219-LM

Optional Ethernet
Bitland RTL8168H 1000M PCIE Ethernet Adapter
Intel®I210-T1 Single Port Gigabit Ethernet Adapter
Intel®I350-T2 Dual Port Gigabit Ethernet Adapter
Intel®I350-T4 Quad Port Gigabit Ethernet Adapter
Internal WiFi Antenna

Optional WLAN
Intel®WiFi 6E AX211 (2x2ax)* with vPro + Bluetooth®5.2

DESIGN
Dimensions (H x W x D) 435mm x 175mm x 508mm / 17.1″ x 6.9″ x 20.0″
Weight Up to 24.5kg / 50lbs
Color Black with iconic ThinkPad red components
SUSTAINABILITY
Material System
65% post-consumer content (PCC) recycled plastic in front and rear bezel
35% PCC recycled plastic inside the chassis

Packaging
Carton: 90% recycled and/or FSC certified content*
Cushion: 90% recycled EPE

Certifications / Registries ENERGY STAR®8.0*
EPEAT®Gold, where applicable**
RoHS Compliant
TCO 9.0
80 Plus Platinum Power Supply
OTHER INFORMATION
ThinkShield Security Trusted Platform Module (TPM) 2.0, TCG certified
Self-healing BIOS
Supervisor (blocks & prevents access to BIOS setup data)
System Management Password (functions similar to Supervisor but with less authority)
Power-on Password (prompts for password directly after pressing the power button)
Firmware Resiliency
UEFI secure boot support
HDD password protection for HDD data
Windows UEFI firmware update support
Windows Device Guard support
Smart USB Protection
Chassis Intrusion Switch
Kensington Security Slot™
Optional: Access panel lock, padlock loop, BIOS Guard, Boot Guard
Power Supply 1000W (92% efficient)
1450W (92% efficient)
Rear power button
ISV Certifications Adobe®
Altair®
ANSYS®
Autodesk®
AVID®
Barco®
Bentley®
Dassault®
McKesson®
Nemetschek®
PTC®
Siemens®
Preloaded Software Lenovo Commercial Vantage (with Windows OS only)
Office 365 trial (with Windows OS only)
What’s in the Box ThinkStation P7 Tower
USB Keyboard
USB Mouse
Quick start guide
