Dell PowerEdge R250
Dell PowerEdge R250
Dell PowerEdge R250
Dell PowerEdge R250
Dell PowerEdge R250
Dell PowerEdge R250

Dell PowerEdge R250

share to:

By using enterprise grade hard drives, high-quality memory, and other hardware components, coupled with strict production processes, the server is ensured to be stable and reliable during long-term operation, reducing the risk of hardware failures and providing strong support for the stable operation of enterprise business

Support ECC memory error correction technology, which can automatically detect and correct data errors, ensure data integrity and accuracy, prevent data loss or system crashes caused by memory errors, and provide additional security for enterprise data

The Dell PowerEdge R250 affordably addresses common business workloads while delivering compute with an entry-level 1U rack server.

Chat Now Contact
Introduction Specifications Gallery Related Products

Introduction

1、The Dell PowerEdge R250 affordably addresses common business workloads while delivering compute with an entry-level 1U rack server.

  • The Dell PowerEdge R250, powered by Intel® Xeon® E-2300 processors, delivers powerful compute for common business applications and streamlines productivity. It supports 3200 MT/s DDR4 speeds and 32 GB DIMMs, up to 128 GB for memory intensive workloads. In addition, to address substantial throughput improvements, the PowerEdge R250 supports PCIe Gen 4 and offers enhanced thermal efficiency to support increasing power and thermal requirements. This makes the PowerEdge R250 an rack ideal server for buisness critical workloads, cloudinfrastructure, and point of sale transactions in a 1U form factor, for small to midsized businesses, inside and outside of the data center.



3、The Dell OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure. Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment.

  • Built-in telemetry streaming, thermal management, and RESTful API with Redfish offer streamlined visibility and control for better server management
  • Intelligent automation lets you enable cooperation between human actions and system capabilities for added productivity
  • Integrated change management capabilities for update planning and seamless, zero-touch configuration and implementation
  • Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible and many other tools



4、The Dell PowerEdge R250 server is designed with a cyber-resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.

  • Operate your workloads on a secure platform anchored bycryptographically trusted booting and silicon root of trust
  • Maintain server firmware safety with digitally signed firmwarepackages
  • Prevent unauthorized configuration or firmware change withsystem lockdown
  • Securely and quickly wipe all data from storage media, includinghard drives, SSDs and system memory with System Erase

Specifications

Processor One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores
Memory • Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s
• Supports unregistered ECC DDR4 DIMMs only
Note: For Pentium processor, the maximum memory speed is 2666 MT/s.
Storage controllers • Internal controllers: PERC H345, H755, HBA355i, S150
• Internal Boot: Internal Dual SD Module or USB or Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs
• External HBAs (non-RAID): HBA355e
Drive bays Front bays:
• Up to 4 x 3.5-inch hot swap SAS/SATA (HDD/SSD) max 30.72 TB
• Up to 2 x 3.5-inch cabled SAS/SATA (HDD/SSD) max 15.36 TB
• Up to 4 x 3.5-inch cabled SAS/SATA (HDD/SSD) max 30.72 TB
Power supplies • 450 W Bronze 100-240 V AC, cabled
• 450 W Platinum 100-240 V AC, cabled
• 700 W Titanium 100-240 V AC, cabled
• 700 W Titanium 240 V DC, cabled
Cooling options Air cooling
Fans • Up to four cabled fans
Dimension • Height: 42.8 mm (1.68 inches)
• Width: 482 mm (18.97 inches)
• Depth: 598.64 mm (23.56 inches) with bezel
 585 mm (23.03 inches) without bezel
Form Factor 1U rack server
Embedded management • iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Manual
Bezel Optional bezel or security bezel
OpenManage Software OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin
Mobility OpenManage Mobile
Integrations and Connections OpenManage Integrations OpenManage Connections
• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager		 • IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI
Security Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC 2 x 1 GbE LOM
GPU options Not supported
Ports Front Ports
• 1 x USB 2.0
• 1 x iDRAC Direct (Micro-AB USB) port		 Rear Ports
• 1 x USB 2.0
• 1 x iDRAC ethernet port
• 1 x USB 3.0
• 1 x VGA
• 1 x Serial port
Internal Ports
• 1 x USB 3.0 (optional)
PCIe 2 PCIe slots:
• 1 x8 Gen4 (x16 connector) low profile, half length
• 1 x8 Gen4 (x8 connector) low profile, half length
Operating System and Hypervisors • Canonical Ubuntu Server LTS
• Microsoft Windows Server with Hyper-V
• SUSE Linux Enterprise Server
• VMware ESXi (support only from Dec’21)
• Red Hat Enterprise Linux
