CloudEngine S6730-H-V2 Series PEN Central Switches
CloudEngine S6730-H-V2 Series PEN Central Switches are Huawei’s next-generation passive Ethernet network (PEN) central switches. They provide 6 x CFP2 PEN downlink central ports + 4 x 25GE ports， 2 x 100GE uplink optical ports , and 1 expansion card slot.
CloudEngine S6730-H-V2 Series PEN Central Switches
CloudEngine S6730-H-V2 Series PEN Central Switches are Huawei’s next-generation passive Ethernet network (PEN) central switches. They provide 6 x CFP2 PEN downlink central ports + 4 x 25GE ports， 2 x 100GE uplink optical ports , and 1 expansion card slot.
CloudEngine S6730-H-V2 Series PEN Central Switches are Huawei’s next-generation enterprise-class core and aggregation switches that feature high performance, high reliability, cloud-based management, and intelligent O&M. Based on Huawei’s industry-leading software and hardware platform, the switches are launched for building high-quality simplified campus networks. Moreover, the switches adopt technologies, such as free mobility, VXLAN, SRv6, and slicing, to deliver ultimate user experience and carrier-class reliability. These make CloudEngine S6730 series switches the ideal core or aggregation switches on a simplified campus network to facilitate digital transformation of global customers. Therefore, they can be widely used in enterprise campuses, universities, data centers, and other application scenarios.
| Product Model | CloudEngine S6730-H6FX4Y2CZ-V2 |
| Switching Capacity2 | 2.52Tbps/4.8Tbps |
| Fixed Ports | 6 x CFP2 PEN central ports，4 x 25GE SFP28, 2 x 100GE QSFP28 ports |
| Power Supply Type | 1+1 backup |
| Expansion Slots | 8 x 10GE or 4 x 25GE optical ports |
| MAC Features | • MAC address auto-learning and aging • Static, dynamic, and blackhole MAC address entries • Packet filtering based on source MAC addresses • MAC address learning limiting based on ports and VLANs |
| VXLAN Features | • Distributed and centralized VXLAN gateways • BGP EVPN • VXLAN configuration through NETCONF • VXLAN route switching |
| iPCA Quality Awareness | • Direct marking of service packets to obtain real-time statistics about dropped packets and packet loss rate • Measurement of the dropped packets and packet loss rate on Layer 2/Layer 3 devices and networks |
| QoS | • Traffic classification based on information from the link layer to the application layer • Complete queue scheduling and congestion control algorithms • Accurate multi-level scheduling for data flows • Hardware-based low-latency QoS queues for multicast packets |
| Interoperability | • VBST (compatible with PVST/PVST+/RPVST) • LNP (similar to DTP) • VCMP (similar to VTP) |
